Wenglor P1KT003 Reflex Sensor Energetic

The reflex sensor works with red light according to the principle of energy and is designed to detect objects without a background. The switching distance is set for a given object. Note that: Bright objects reflect transmitted light better than dark objects. Dark (matte) objects can also be differentiated from bright (glossy) objects. This means that presence or stack height checks can be conducted or counting tasks carried out. The IO-Link interface can be used to configure the reflex sensors (PNP/NPN, NC/NO, switching distance), as well as for reading out switching statuses and distance values.

Features at a Glance

Condition monitoring

Large detection range

High switching frequency

IO-Link 1.1

Optical Data

Range	700 mm
Switching Hysteresis	< 10 %
Light Source	Red Light
Service Life (T = +25 °C)	100,000 h
Max. Ambient Light	10,000 Lux

Electrical Data

Supply Voltage	10 … 30 V DC
Supply Voltage with IO-Link	18 … 30 V DC
Current Consumption (Ub = 24 V)	< 20 mA
Switching Frequency	500 Hz
Switching frequency (speed mode)	1,000 Hz
Response Time	1 ms
Response time (speed mode)	0.5 ms
Temperature Drift	< 10 %
Temperature Range	-40 … 60 °C
Switching Output Voltage Drop	< 2 V
Switching Output/Switching Current	100 mA
Residual Current Switching Output	< 50 µA
Short Circuit Protection	yes
Reverse Polarity Protection	yes
Overload Protection	yes
Lockable	yes
Interface	IO-Link V1.1
Protection Class	III

Mechanical Data

Setting Method	Potentiometer
Housing Material	Plastic, ABS/PC
Degree of Protection	IP67/IP68
Connection	M8 × 1; 4-pin
Optic Cover	Plastic, PMMA
Weight	6 g

Safety Relevant Data

MTTFd (EN ISO 13849-1)

2,630.72 a

Output

IO-Link	yes
NPN NC, NPN NO	yes

Adjustable Parameter

Output	Push-pull NPN PNP
Circuit	inactive Error output NC NC+NO NO
Other parameters	Off-delay On-delay Mode of operation Hysteresis Switching point Emitted light
