Patlite LR4 Series 40mm LED Signal Tower Lights is a Re-designed lens and improved module construction delivering bright, even light for visibility from further distances. Re-engineered, completely enclosed sound module maintains substantial water and dust protection while producing loud, omnidirectional sound. (LR5 DC12V: 80dB LR4 & LR5: 85dB, LR6: 88dB, LR7: 90dB at 1m), A modular, “Twist and Lock”, design to easily customize and field configure LED units and sound modules. A sleek, smooth form factor and rugged body construction for performance in harsh environments, carrying an IP65 protection rating. Next-generation signal tower series featuring ultra-bright LEDs, a modular design, and a wide selection of options to take on the most challenging applications.
Story Of Patlite
Since 1947, PATLITE has offered state-of-the-art equipment for the process and industrial automation industries. Innovative and durable design, backed by years of industry experience and a strong commitment to safety and security, has made PATLITE the world’s best-known manufacturer of visual and audible signaling devices. Headquartered in Japan, PATLITE has more than 1000 employees worldwide with wholly-owned sales subsidiaries in the USA, Mexico, Germany, Singapore, Korea, Thailand, Taiwan, and China.
Features
- Re-designed lens and improved module construction delivering bright, even light for visibility from further distances.
- The re-engineered, completely enclosed sound module maintains substantial water and dust protection while producing loud, omnidirectional sound. (LR5 DC12V: 80dB LR4 & LR5: 85dB, LR6: 88dB, LR7: 90dB at 1m)
- A modular, “Twist and Lock”, design to easily customize and field configure LED units and sound modules.
- A sleek, smooth form factor and rugged body construction for performance in harsh environments, carrying an IP65 protection rating.
- Four mounting options: Direct, pole with L-bracket, pole with circular bracket, and pole with folding bracket (Off-white only).
- Available in DC24V and AC100-240V (Off-white only).
- Available in Off-white and Silver bodies.
- Available with a Clear lens (special order).
Applications
- Control/Switchboard Panel Lighting
- Machinery
- Equipment Lighting
Specifications
| Operating Ambient Temperature | -20? – +50? |
|---|---|
| Operating Humidity Range | 90% RH or less, no condensation |
| Storage Temperature Range | -30? – +60? |
| Storage Humidity Range | 90% RH or less, no condensation |
| Mounting Location | Indoor Use |
| Mounting Direction | Upright Position |
| Protection Rating*1 | IP65(IEC 60529) / NEMA TYPE 4X, 13 |
| Environmental Conditions | Upright Position |
| Insulation Resistance | More than 1M? at DC500V between the power input lead and chassis |
| Withstand Voltage | AC 500V for 1 minute between terminals and chassis without breaking insulation (M2: AC1500V for 1 min.) |
| Flash Rate | 60 ±2 Flashes/min |
| Sound Level | LR4Typ. 85dB |
| Sound Reduction*2 | ab. -10dB reduction |
| Environmental Conditions | Buzzer Sound No.4 (Sweep) from all directions at a 1m distance |
| Buzzer Sound | 4 patterns*2?No.1Rapid Intermittent sound?No.2Continuous sound?No.3Rapid Hi-low?No.4Sweep sound |
| Transistor Output | NPN / PNP (AC100 – 240V is NPN only) |
| Conformity Standards | ?UL 508, CSA-C22.2 No.14 ?FCC Part 15 Subpart B Class A ?RoHS Directive (EN IEC 63000) ?EMC Directive (EN 61000-6-4, EN 61000-6-2) ?KC (KN 61000-6-4, KN 61000-6-2)*3 ?Low-voltage Directive (IEC/EN 60947-5-1, EN62471)*4 |
