Sibas Insert Connectors

Sibas Insert Connectors HD.64.BU.C HDC

Sibas Connector HD.64.BU.C HDC Inserts
Sibas Connector HD.64.BU.C HDC Inserts

Product Type Features

  • Product Size?: 8
  • Product Type?: Insert
  • HTS Housings and Hoods?: No

Configuration Features

  • Number of Positions?:64

Electrical Characteristics

  • Power Circuit Voltage?(V): 250
  • Power Circuit Current?(A): 10

Body Features

  • Insert Style?: Socket
  • Color?: Gray
  • Material?: PC

Contact Features

  • Contact Type?: Pin
  • Number of Poles?:64+PE

Packaging Features

  • Packaging Quantity?:5
  • Packaging Method?: Loose Piece

Other

  • Comment?: Use HD.M Contacts, Use two 64 position inserts to form 128 position insert

Sibas Insert Connectors HVT.48.BU.C.SO-SB

Sibas Insert HVT.48.BU

Product Type Features

  • Product Size? 8
  • Product Type? Insert
  • HTS Housings and Hoods? No
  • Applies To? Screened Cable (Shielded)

Electrical Characteristics

  • Power Circuit Voltage?(V) 400
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Socket
  • Material? Glass-Filled Thermoplastic

Contact Features

  • Number of Poles? 48
  • Operation/Application
  • For Use With? Use with HTS Series HVT contacts

Packaging Features

  • Packaging Quantity? 5
  • Packaging Method? Box

Other

  • Comment? Use with HTS Series HVT contacts

Sibas Insert Connector HVT.14.STI.C.SO-SB

Sibas Insert HVT.14.STI.C.SO-SB
Sibas Insert HVT.14.STI.C.SO-SB

Product Type Features

  • Product Size? 4
  • Product Type? Insert
  • HTS Housings and Hoods? No
  • Applies To? Screened Cable (Shielded)

Electrical Characteristics

  • Power Circuit Voltage?(V) 400
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Pin
  • Material? Glass-Filled Thermoplastic

Contact Features

  • Number of Poles? 14
  • Operation/Application
  • For Use With? Use with HTS Series HVT contacts

Packaging Features

  • Packaging Quantity? 5
  • Packaging Method? Box

Other

  • Comment? Use with HTS Series HVT contacts

Sibas Insert Connectors HA.16.STI.C.B 33-48

Product Type Features

  • Product Size? 9
  • Product Type? Connector
  • HTS Housings and Hoods? No
  • Applies To? Panel

Configuration Features

  • Number of Positions? 16

Electrical Characteristics

  • Power Circuit Voltage?(V) 250
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Pin
  • Color? Beige
  • Material? PBT

Contact Features

  • Contact Type? Socket
  • Number of Poles? 16+PE

Packaging Features

  • Packaging Quantity? 10
  • Packaging Method? Loose Piece

Other

  • Comment? Use in conjunction with P/Ns 2-1103416-3 and 2-1103416-7 to form 48 position insert., Use with HTS Series HE/HA contacts

Sibas Male Insert Crimp 4-POS. 22DF Contact

MALE INSERT, CRIMP, 4-POS. 22DF CONTACTS
MALE INSERT, CRIMP, 4-POS. 22DF CONTACTS

MALE INSERT, CRIMP, 4-POS. 22DF CONTACTS Sibas is compatible with Male insert housing and pin contact,22-28 AWG, 22 DF, Amplimite. There are very suitable for power and signal operation/application.

Features

  • Product Type?: Insert

Body Features

  • Insert Style?: Pin
  • Color?: Gray
  • Material?: PBT GF10

Contact Features

  • Contact Configuration?: Crimp Terminal
  • Number of Poles?: 4

Dimensions

  • Wire Range : .08 – .4?mm²?[?28 – 22?AWG?]

Operation/Application

  • For Use with Series?: Power4Net

Packaging Features

  • Packaging Quantity?: 40
  • Packaging Method?: Carton

Other

  • Comment?: Contacts sold separately., See drawing for additional product information.

Sibas Insert HA.16.BU.SC.B 49-64

Insertion Connector HA.16
Insertion Connector HA.16

Product Type Features

  • Product Size? 11
  • Product Type? Connector
  • HTS Housings and Hoods? No
  • Applies To? Panel

Configuration Features

  • Number of Positions? 16

Electrical Characteristics

  • Power Circuit Voltage?(V) 250
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Socket
  • Color? Beige
  • Material? PBT

Contact Features

  • Contact Type? Pin
  • Number of Poles? 16+PE

Packaging Features

  • Packaging Quantity? 10
  • Packaging Method? Loose Piece

Other

  • Comment? Use in conjunction with P/Ns 7-1103417-1, 7-1103417-7 and 7-1103417-8 to form 64 position insert.

Sibas Insert HA.16.BU.SC.B 33-48

Insertion Connector HA.16
Insertion Connector HA.16



Product Type Features

  • Product Size? 9
  • Product Type? Connector
  • HTS Housings and Hoods? No

Configuration Features

  • Number of Positions? 16

Electrical Characteristics

  • Power Circuit Voltage?(V) 250
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Socket

Contact Features

  • Contact Type? Pin
  • Number of Poles? 16+PE

Packaging Features

  • Packaging Quantity? 5
  • Packaging Method? Loose Piece

Other

  • Comment? Use in conjunction with P/Ns 7-1103417-1 and 7-1103417-7 to form 48 position insert.

Sibas Insert Connectors HA.16.STI.SC.B49-64

Insertion Connector HA.16
Insertion Connector HA.16

Product Type Features

  • Product Size? 11
  • Product Type? Connector
  • HTS Housings and Hoods? No
  • Applies To? Wire/Cable

Configuration Features

  • Number of Positions? 16

Electrical Characteristics

  • Power Circuit Voltage?(V) 250
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Pin
  • Color? Beige
  • Material? PBT

Contact Features

  • Contact Type? Socket
  • Number of Poles? 16+PE

Operation/Application

  • For Use With? Panel

Packaging Features

  • Packaging Quantity? 10
  • Packaging Method? Loose Piece

Other

  • Comment? Use in conjunction with P/Ns 7-1103416-1, 7-1103416-7 and 7-1103416-8 to form 64 position insert.

Sibas Insert Connectors HA.16.STI.SC.B33-48

Insertion Connector HA.16
Insertion Connector HA.16

Product Type Features

  • Product Size? 9
  • Product Type? Connector
  • HTS Housings and Hoods? No
  • Applies To? Wire/Cable

Configuration Features

  • Number of Positions? 16

Electrical Characteristics

  • Power Circuit Voltage?(V) 250
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Pin
  • Color? Beige
  • Material? PBT

Contact Features

  • Contact Type? Socket
  • Number of Poles? 16+PE
  • Operation/Application
  • For Use With? Panel

Packaging Features

  • Packaging Quantity? 10
  • Packaging Method? Loose Piece

Other

  • Comment? Use in conjunction with P/Ns 7-1103416-1 and 7-1103416-7 to form 48 position insert.

Sibas Insert Connectors HA.16.STI.SC.B17-32

Insertion Connector HA.16
Insertion Connector HA.16

Product Type Features

  • Product Size? 7
  • Product Type? Connector
  • HTS Housings and Hoods? No
  • Applies To? Wire/Cable

Configuration Features

  • Number of Positions? 16

Electrical Characteristics

  • Power Circuit Voltage?(V) 250
  • Power Circuit Current?(A) 16

Body Features

  • Insert Style? Pin
  • Color? Beige
  • Module Material? PBT

Contact Features

  • Contact Type? Socket
  • Number of Poles? 16+PE
  • Operation/Application
  • For Use With? Panel

Packaging Features

  • Packaging Quantity? 10
  • Packaging Method? Loose Piece

Other

  • Comment? Use in conjunction with P/N 7-1103416-1 to form 32 position insert.
