Overview
J. Schneider CEM 24-16, Capacitor Extension Module. The CEM module is used to increase the buffer energy for the devices C-TEC 2403-05; 2403-1; 2420-8 and 2440P as well as for the devices AC C-TEC 2403-05; AC C-TEC 2403-1; AC C-TEC 2403-1-400; AC C-TEC 2420-8. The C-TEC monitors and controls the charging and discharging of the extension modules.
J. Schneider CEM 24-16 Technical Data
| Nominal input voltage | 24 V DC |
| Input voltage range | 0… 26,4 V DC 0…24 V DC +10% |
| Buffer capacity | 16 kJ |
| Nominal input current | 20 A DC |
| Nominal output current | 20 A DC |
| Fusing input | 25 A T (PTC internal) |
| Fusing DC output circuit | 25 A T (PTC internal) |
| Type of connection input ,C+/C-‘ | Spring terminal max. 4mm² |
| Type of connection output ,C+/C-‘ | Spring terminal max. 4mm² |
| Protective system | IP 20 and EN 60529 |
| Storage temperature | – 40… 60 °C |
| Environmental temperature | – 40… 60°C |
| Relative humidity | 95 % non-condensing |
| Max. mounting height (without load reduction) | 2000 m above sealevel |
| Dimensions (H x W x D) | 193 mm x 82 mm x 193 mm |
| Weight | 2,54 kg |
| Fixation | Snap-on mounting for DIN top hat rail or mounting bracket for mounting plate |
| Norms and Regulations | EN 50178 / EN 60950 |
| UL approvals | No |
